Compatible Controllers List
Below you will find extensive information about all of the different controllers you can use with our systems. Please read carefully as everything is outlined in great detail. If you still need help AFTER reading the information below, feel free to email us at arcadeonesystems@gmail.com
Generally speaking, any controller that is Xinput compatible or has an IPAC encoder will work. Many controllers and fight sticks support Xinput.
The following link will take you to a playlist which is full of videos outlining the details about the different controller options you can use with our systems:
Disclosure: This page may contain affiliate links, meaning we get a commission if you decide to make a purchase through our links, at no cost to you.
Handheld Controllers
8BitDo Controllers
8BitDo controllers are plug and play with our systems. These are our current recommended controllers due to their outstanding quality, good color choices and are affordability.
Please note that you want to connect all of these with the included 2.4GHz dongle and not through Bluetooth. If the controller has a charging dock, the dongle will be in a compartment underneath the charging dock. Also, if the controller has a switch on the back, make sure that it is set to “X” or “2.4G” and NOT “D” or Bluetooth.
Below are the specific models that we have tested and can guarantee to work with our systems:
8Bitdo Ultimate 2.4G Wireless Controller
DETAILS: Xbox button layout, includes charging dock.
8Bitdo Ultimate Bluetooth Controller
DETAILS: Nintendo button layout, includes charging dock.
8Bitdo Ultimate C 2.4g Wireless Controller
DETAILS: pay attention when ordering these, there is a “C” version and a “2C” version. You want the “C” and NOT the “2C”.
Original Xbox 360 Controllers
Original Microsoft branded Xbox 360 controllers are plug and play. These can be purchased anywhere they’re sold or you can use your existing controllers as long as they’re original Microsoft branded and not third party.
Both wired or wireless controllers will work. If using wireless you will need a wireless receiver. A single receiver will work for up to 4 controllers, you DO NOT need one wireless receiver per controller.
Xbox 360 Controllers On eBay (read the description to make sure they’re original)
Xbox 360 Wireless Receiver On eBay (read the description to make sure they’re original)
Xbox 360 Third Party Wireless Receiver (buy this one if you aren’t able to source an original receiver, these will work with original Xbox 360 controllers. Only 1 receiver is needed for up to 4 controllers)
See the following instructions for installing the drivers for these third party receivers.
Windows 7 Instructions
Windows 10 Instructions
Third Party Xbox 360 Controllers
These are our recommended and tested third party Xbox 360 controllers in case you are not able to source original Microsoft branded controllers. Note that third party controllers each include their own receiver, you will need to plug in one receiver for each controller.
Voyee Wireless Xbox 360 Controllers
Voyee Wired Xbox 360 Controllers
W&O Wireless Xbox 360 Controllers
Original Xbox One / Series X / Series S Controllers
2TB, Budget 2TB and CRT GroovyMAME Systems
For the 2TB, Budget 2TB and CRT GroovyMAME systems, you can use up to 4 Xbox One / Series X / Series S controller. For these systems, you must use one of the following wireless receivers:
8TB and 20TB System
If using a single controller, you will need one of the following receivers:
If playing games with 2 or more players on the 8TB or 20TB systems, it is recommended to use Xbox 360 controllers or the third party Xbox One controllers below. If you still want to use original Xbox One controllers for multiplayer gaming, you can do so by pairing each Xbox One controller to one of the following 8Bitdo wireless adapters, more on that in the 8Bitdo section.
Third Party Xbox One / Series X / Series S Controllers
These controllers work well and Windows recognizes them as Xbox 360 controllers. Each controller includes a wireless dongle, you cannot pair multiple controllers to a single dongle.
Riboxin Xbox One Controllers
Original Playstation 4 & Playstation 5 Controllers
Below are two videos showing how to easily pair original Playstation 4 or Playstation 5 controllers to your Arcade-One system. The first video is shorter for quick set up and the second one goes into more detail.
TP-Link Bluetooth Adapter shown in video:
Third Party Playstation Controllers
The controllers below also work great and are extremely affordable. The first two connect through Bluetooth and the GameSir controllers each include their own receiver.
FASIGO PS4 Controller 2 Pack
These controllers will connect through Bluetooth same as original PS4/PS5 controllers. Follow the same process show in the videos below.
SHINXIN PS4 Controller 2 Pack
These controllers will connect through Bluetooth same as original PS4/PS5 controllers. Follow the same process show in the videos below.
GameSir T3s Controllers
These controllers work well and Windows recognizes them as Xbox 360 controllers. Each controller includes a wireless dongle, you cannot pair multiple controllers to a single dongle.
Any controller connected through one of these adapters is recognized as an Xbox controller meaning Windows will think you are playing with an Xbox controller even if you’re not! These adapters support many controllers, we have tested the following for 2 player gameplay:
– Sony Playstation 4 Controllers
– Sony Playstation 5 Controllers
– Microsoft Xbox One Controllers (must be model 1708 or newer, the really old model 1697 controllers won’t work)
– 8Bitdo Bluetooth Controllers (we haven’t tested them all but any 8Bitdo Bluetooth Controller such as the SN30 Pro should work)
Please note that you need one 8Bitdo Wireless Adapter per controller. You’ll also want to put the adapter in Xinput mode. Instructions for that can be found on the 8Bitdo support page HERE.
Scroll down, choose the black USB Adapter 2, click on “Manual” and select the controller you’re using, then select Windows. Look at the “manual setting” section under FAQ to see how to put the adapter into Xinput mode.
8Bitdo Wireless USB Adapter
Fight Sticks
These fight sticks are plug and play. There is a physical mod that we recommend you do but isn’t mandatory. See our video tutorial below for details.
Mayflash F300 Fight Stick
Mayflash F300 Elite Fight Stick
Mayflash F500 Fight Stick
Mayflash F500 Elite Fight Stick
Arcade Style Controllers
These are high quality controllers and are virtually plug and play. See our video below for quick set up instructions.
Rec Room Masters Xtension Controllers
These controllers require minimal set up. See our easy to follow videos below for instructions. NOTE: if you have a newer X-Arcade controller (2019 and beyond) use the first video. If you have an older controller (before 2019) use the second video.
CLICK HERE to download our key mapping diagram
X-Arcade Tankstick
Instructions for Tanksticks manufactured from 2019 and beyond:
Instructions for Tanksticks manufactured before 2019:
Light Guns
Sinden light guns require minor initial set up using our automated installer. See main set up video below which will get 95% of the games working. Some games/systems require individual set up, videos for those are below as well. In addition, click here to access a playlist for all Sinden related videos on our YouTube channel.
Sinden Light Guns
Main set up video
The following games/systems require additional set up
Aimtrak light guns require minor initial set up. See videos below for instructions.
Aimtrak Light Guns
Teknoparrot games require additional setup using our Teknoparrot Gun Wizard:
Steering Wheels
The Logitech G29 Steering Wheel is plug and play with our systems. See videos for steps that need to be performed before using the wheel. The first video is long because we go into a lot of detail, but enabling it is simple and most of the video just shows you how to do different things like changing the inputs should you choose to do so.
Note: you must use the Logitech G29, NOT the G920.
Guitars
You can use just about any guitar brand to play Guitar Hero, Rock Band or Clone Hero. See video below for more details on the guitars that we have tested and also to find out which guitars are pre-configured out of the box for you!
Wii Wired Guitars (Recommended):
Wii Wireless Guitars:
